Wednesday, September 27, 2017

How to use SKP1000 to add a Honda CRV 2009 key

Guide to add a Honda CR-V 2009 straight key by using SKP1000 car key programmer via OBD.

Key info:
Original key: 3-button straight key
Chip: ID46 chip
Pin Code: without pin code
Device to program: SKP 1000 tablet auto key programmer

Procedure:
Connect SKP1000 key programmer with CRV 2009 via OBD diagnostic socket
Select IMMOBILIZER function->Honda->By System->Electronic Immobilizer System 2-> Immobilizer system
skp1000-honda-crv-2009-1
skp1000-honda-crv-2009-2
skp1000-honda-crv-2009-3
skp1000-honda-crv-2009-4
Choose OBDII connector
Turn ignition to ON position
Press YES
skp1000-honda-crv-2009-5
Configuring system, please wait for about 1 minute
skp1000-honda-crv-2009-6
Select Add a key
skp1000-honda-crv-2009-7
Insert key registered and turn ignition on
Press YES to continue
skp1000-honda-crv-2009-8
Switch key to ON position
skp1000-honda-crv-2009-9
Insert a new key within 1 second
and turn ignition on
skp1000-honda-crv-2009-10
Switch key to ON position
skp1000-honda-crv-2009-11
SKP1000 Program Honda CRV 2009 key success.
skp1000-honda-crv-2009-12

Tuesday, September 26, 2017

How to use SKP1000 to add key for 2012 Ford Mondeo Ghia X

Here’s the guide to use SKP1000 car key programmer to add a folding key to a Ford Mondeo Ghia X 2012.

Key info:
Original key: 3-button folding key
Frequency: 433MHz
Chip: 83 chip
Device to program: SKP 1000 tablet auto key programmer

Guide:
Connect SKP1000 key programmer with vehicle via OBD
Select Ford->Mondeo Ghia X> 2012 Ghia X
skp1000-ford-mondeo-1
skp1000-ford-mondeo-2
skp1000-ford-mondeo-3
Select Add a Key
skp1000-ford-mondeo-4
Insert a new key
Turn ignition to ON position
Press YES to continue
skp1000-ford-mondeo-5
SKP-1000 detect current key number: 2
Press YES
skp1000-ford-mondeo-6
Configuring system, please wait
skp1000-ford-mondeo-7
SKP1000 see key number: 3
skp1000-ford-mondeo-8
Add key success.
skp1000-ford-mondeo-9

Sunday, September 24, 2017

SKP1000 Program Cadillac SRX 2013 Smart Key

How to read security pin code and add a smart key to a Cadillac SRX 2013 by using SKP1000 car key programmer via OBD.

Key information:
Original key: 5-button smart card
Frequency: 315MHz
Chip: ID46 chip
Pin Code: read by SKP1000
Device to program: SKP 1000 tablet key programmer

Procedure:
Step 1: Read PIN Code
Connect SKP1000 key programmer with vehicle via OBD
Turn ignition ON
Select Cadillac->SRX->Read Pin code->System 1
skp1000-cadillac-srx-1
skp1000-cadillac-srx-2
skp1000-cadillac-srx-3
skp1000-cadillac-srx-4
skp1000-cadillac-srx-5
SKP-1000 read vehicle VIN then pin code
skp1000-cadillac-srx-6
skp1000-cadillac-srx-7
Step 2: Program Smart Key
Select 2010-2015 Smart key-> Smart key system
skp1000-cadillac-srx-8
Choose OBDII Connector
Turn ignition OFF
Press YES
skp1000-cadillac-srx-9
Current key number: 2
skp1000-cadillac-srx-10
Choose Program Smart key entry
skp1000-cadillac-srx-11
Please insert a new key into slot and take other keys out of car
skp1000-cadillac-srx-12
skp1000-cadillac-srx-13
SKP1000 auto key programmer require to enter 4-digit security code
skp1000-cadillac-srx-14
Configuring system, please wait for 12 minutes
Then press on the Start button for once
skp1000-cadillac-srx-15
Whether to program next key? Press YES
skp1000-cadillac-srx-16
Put new key into slot, press YES to continue
skp1000-cadillac-srx-17
Press on the START button for once
Program next key? Press YES
Press on the Start button for 12s
skp1000-cadillac-srx-18
Keep pressing on the START button until ignition to ON position
skp1000-cadillac-srx-19
Configuring system
Press on START button
Turn ignition OFF
skp1000-cadillac-srx-20
Configuring system,please wait for 30s
All keys must be synchronized with the car
Press YES
skp1000-cadillac-srx-21
Press Start Button and start engine
Press Start Button and then turn off engine
skp1000-cadillac-srx-22
skp1000-cadillac-srx-23
Follow SKP1000 prompt,
  1. Take key out of the slot
2. Press the LOCK button on the key
3. Press the UNLOCK button on the key
skp1000-cadillac-srx-24
Sync more keys?
Press YES
skp1000-cadillac-srx-25
Follow steps above to add next key
Insert next key into slot
Take away other keys
Press Start Button and start engine
Configuring system…
Press Start Button and then turn off engine
  1. Take key out of the slot
2. Press the LOCK button on the key
3. Press the UNLOCK button on the key
Sync more keys?
Press NO
Configuring system…
Current key: 2
skp1000-cadillac-srx-27
Program success.
skp1000-cadillac-srx-28

Friday, September 22, 2017

How to use SKP1000 to Program Chrysler Sebring 2008 Key

Here’s the guide to use SKP1000 car key programmer to read security pin code and add a straight remote key on a Chrysler Sebring 2008.
skp1000-Chrysler-Sebring-1
Key information:
Original key: 3-button Straight remote key
Chip: ID46
Frequency: 433MHz
Pin code: YES (Read by SKP 1000)
Device to program: SKP1000 tablet auto key programmer.

Procedure:
Step 1: Read Pin Code
Connect SKP1000 key programmer with vehicle via OBD socket
Select Chrysler->Immobilizer system (straight remote key)-> Immobilizer system
skp1000-Chrysler-Sebring-2
skp1000-Chrysler-Sebring-3
skp1000-Chrysler-Sebring-4
Choose OBDII connector
Turn ignition to ON position
Press YES
skp1000-Chrysler-Sebring-5
Select Read Pin Code function
skp1000-Chrysler-Sebring-6
Read pin code success
skp1000-Chrysler-Sebring-7
Step 2: Program key
Select Add a key function
skp1000-Chrysler-Sebring-8
Insert a new key to be programmed
Turn ignition ON
Press YES
skp1000-Chrysler-Sebring-9
SKP1000 will require to enter pin code to program key
Enter 4-digit security code and confirm
skp1000-Chrysler-Sebring-10
skp1000-Chrysler-Sebring-11
Program success will generate remote automatically.
skp1000-Chrysler-Sebring-12
Test the remote key.
